Motor structure: Outer rotor motor 92mm
Safety: Thermal protection
Operating system: High-precision double ball bearing
Withstand voltage: AC 1800V, at 0.5mA, 50/60Hz
Allowable ambient temperature and humidity: -25℃~75℃, 10%~80%
Insulation level: F(IEC61858 standard)
IP level: IP44
Weight: 1.27Kg
Material: Fan blade: PA nylon, 7 blades; Bearing: NSK ball bearing; Motor life: 60000 hours at 25℃
| Model | Frequency | Current | Voltage | Power | Speed | Air Flow | Air Volume | Noise |
|---|---|---|---|---|---|---|---|---|
| V | Hz | A | W | RPM | CFM | m³/h | dB | |
| C2S-190.45A | 115 | 50 | 0.64 | 65 | 2500 | 336 | 570 | 59 |
| 60 | 0.65 | 71 | 2700 | 366 | 620 | 61 | ||
| C2E-190.45A | 230 | 50 | 0.26 | 58 | 2500 | 336 | 570 | 59 |
| 60 | 0.33 | 74 | 2700 | 366 | 620 | 61 | ||
| C2D-190.45A | 400 | 50 | 0.17 | 63 | 2500 | 336 | 570 | 59 |
| 60 | 0.19 | 73 | 2700 | 366 | 620 | 61 | ||
| C4E-190.45A | 230 | 50 | 0.13 | 27 | 1400 | 182 | 310 | 48 |
| 60 | 0.12 | 27 | 1600 | 212 | 360 | 51 |
