The Trusted Source for Durable Cooling Fans
Bearings: Ball bearings
Material: Impeller: Plastic; Frame: Aluminum Alloy
Lead Wire: UL Type
Insulation level: Class B
Working temperature: -10℃~70℃
Weight: 1800g
| Model | Voltage | Current | Speed | Air Pressure | Air Flow | Noise |
|---|---|---|---|---|---|---|
| V | A | RPM | mmH2O | CFM | dB | |
| LK20572H12B | 12 | 8.0 | 3000 | 31.7 | 728.4 | 59 |
| LK20572H24B | 24 | 5.0 | 3300 | 36.6 | 798.3 | 62 |
| LK20572M24B | 24 | 4.0 | 2700 | 25.2 | 646.3 | 57 |
| LK20572L24B | 24 | 3.0 | 2200 | 16.9 | 531.3 | 51 |
| LK20572H48B | 48 | 2.0 | 3300 | 36.6 | 798.3 | 62 |
| LK20572M48B | 48 | 1.5 | 2700 | 25.2 | 646.3 | 57 |
| LK20572L48B | 48 | 1.2 | 2200 | 16.9 | 531.3 | 51 |
