The Trusted Source for Durable Cooling Fans
Bearings: Ball bearings
Material: Impeller: Plastic; Frame: Aluminum Alloy
Lead Wire: UL Type
Insulation level: Class B
Working temperature: -10℃~70℃
Weight: 2100g
| Model | Voltage | Current | Speed | Air Pressure | Air Flow | Noise |
|---|---|---|---|---|---|---|
| V | A | RPM | mmH2O | CFM | dB | |
| LK25489H12B-7 | 12 | 8.0 | 2500 | 24.8 | 796.7 | 55 |
| LK25489H24B-7 | 24 | 4.0 | 2800 | 26.9 | 894.9 | 58 |
| LK25489M24B-7 | 24 | 2.0 | 2400 | 22.8 | 762.2 | 53 |
| LK25489L24B-7 | 24 | 0.8 | 2000 | 22.8 | 628.3 | 48 |
| LK25489H48B-7 | 48 | 2.0 | 3000 | 15.8 | 970.1 | 59 |
| LK25489M48B-7 | 48 | 1.0 | 2500 | 24.8 | 796.7 | 55 |
| LK25489L48B-7 | 48 | 0.6 | 2000 | 15.8 | 628.3 | 48 |
