The Trusted Source for Durable Cooling Fans
Bearings: Sleeve or ball bearings
Material: PBT 7 fan blade
Motor life: 30000 hours (sleeve) / 50000 hours (ball)
Insulation level: Class A
Working temperature: -20℃~60℃
Weight: 72g
| Model | Voltage | Current | Power | Speed | Air Flow | Noise |
|---|---|---|---|---|---|---|
| V | A | W | RPM | CFM | dB | |
| LK8025L12B | 12 | 0.08 | 0.08 | 2500 | 26.67 | 29.2 |
| LK8025L24B | 24 | 0.04 | 0.04 | |||
| LK8025M12B | 12 | 0.13 | 0.13 | 3000 | 33.46 | 33.5 |
| LK8025M24B | 24 | 0.07 | 0.07 | |||
| LK8025H12B | 12 | 0.25 | 0.25 | 4000 | 44.05 | 41.2 |
| LK8025H24B | 24 | 0.12 | 0.12 | |||
| LK8025H48B | 48 | 0.06 | 0.06 |
