The Trusted Source for Durable Cooling Fans
Bearings: Sleeve or ball bearings
Material: PBT 7 fan blade
Motor life: 30000 hours (sleeve) / 50000 hours (ball)
Insulation level: Class A
Working temperature: -20℃~60℃
Weight: 102g
| Model | Voltage | Current | Power | Speed | Air Flow | Noise |
|---|---|---|---|---|---|---|
| V | A | W | RPM | CFM | dB | |
| LK9225L12B | 12 | 0.13 | 1.56 | 2500 | 38.12 | 31.7 |
| LK9225L24B | 24 | 0.06 | 1.44 | |||
| LK9225L48B | 48 | 0.04 | 1.92 | |||
| LK9225M12B | 12 | 0.25 | 3.00 | 3500 | 53.3 | 38.5 |
| LK9225M24B | 24 | 0.12 | 2.88 | |||
| LK9225M48B | 48 | 0.06 | 2.88 | |||
| LK9225H12B | 12 | 0.52 | 6.24 | 4500 | 73.2 | 45.8 |
| LK9225H24B | 24 | 0.25 | 6.00 | |||
| LK9225H48B | 48 | 0.13 | 6.24 |
