Bearings: Sleeve or ball bearings
Material: PBT 7 fan blade
Motor life: 30000 hours (sleeve) / 50000 hours (ball)
Insulation level: Class A
Working temperature: -20℃~60℃
Weight: 202g
| Model | Voltage | Current | Power | Speed | Air Flow | Noise |
|---|---|---|---|---|---|---|
| V | A | W | RPM | CFM | dB | |
| LK9238L12B-HP | 12 | 0.27 | 3.24 | 4000 | 67.27 | 46.9 |
| LK9238L24B-HP | 24 | 0.15 | 3.60 | |||
| LK9238L48B-HP | 48 | 0.08 | 3.84 | |||
| LK9238M12B-HP | 12 | 0.90 | 10.80 | 6000 | 100.98 | 56.6 |
| LK9238M24B-HP | 24 | 0.50 | 12.00 | |||
| LK9238M48B-HP | 48 | 0.25 | 12.00 | |||
| LK9238H12B-HP | 12 | 1.80 | 21.60 | 7500 | 126.12 | 61.9 |
| LK9238H24B-HP | 24 | 0.90 | 21.60 | |||
| LK9238H48B-HP | 48 | 0.45 | 21.60 |
