The Trusted Source for Durable Cooling Fans
Bearings: Sleeve or ball bearings
Material: Impeller & Frame: Plastic(UL94-V0)
Lead Wire: UL Type
Working temperature: -10℃~70℃
Insulation level: Class B
Weight: 140g
| Model | Voltage | Current | Frequency | Operation Voltage | Power | Speed | Air Pressure | Air Volume | Noise |
|---|---|---|---|---|---|---|---|---|---|
| V | A | Hz | VAC | W | RPM | mmH₂O | CFM | dB | |
| LKE12025HB | 110/240 | 0.16/0.08 | 50/60 | 90/265 | 7 | 2600 | 4.5 | 79.6 | 33 |
| LKE12025MX | 110/240 | 0.12/0.06 | 4 | 2200 | 3.4 | 68.0 | 28 | ||
| LKE12025LX | 110/240 | 0.10/0.05 | 3 | 1800 | 2.5 | 55.6 | 23 |
