Bearings: Ball bearings
Material: Impeller & Frame: Plastic(UL94-V0)
Lead Wire: UL Type
Working temperature: -10℃~70℃
Insulation level: Class B
Weight: 2100g
| Model | Voltage | Current | Frequency | Operation Voltage | Power | Speed | Air Pressure | Air Volume | Noise |
|---|---|---|---|---|---|---|---|---|---|
| V | A | Hz | VAC | W | RPM | mmH₂O | CFM | dB | |
| LKE25489HB | 110/120 | 2.00/1.10 | 50/60 | 90/135 | 145 | 3200 | 27.1 | 981.6 | 60 |
| LKE25489MB | 110/120 | 1.80/0.90 | 115 | 2500 | 24.8 | 796.7 | 55 | ||
| LKE25489LB | 110/120 | 1.60/0.80 | 110 | 2000 | 15.8 | 628.3 | 48 | ||
| LKE25489H2B | 220/240 | 1.10 | 50/60 | 190/265 | 145 | 3200 | 27.1 | 981.6 | 60 |
| LKE25480M2B | 220/240 | 0.90 | 115 | 2500 | 24.8 | 796.7 | 55 | ||
| LKE25589L2B | 220/240 | 0.80 | 100 | 2000 | 15.8 | 628.3 | 48 |
